High precision, high stability, low noise thin Ball bearings Suppliers

High precision, high stability, low noise thin Ball bearings

High precision, high stability, low noise thin Ball bearings

DZ industrial.


Location:China
Business Type:Manufacturer, Exporter
Brands:
Certificate:ISO and TS
Model:
Terms of payment and delivery:Lc / TT 45days
Minimum order quantity:1000pcs
Price:contact
Packing details:industrial packing or box

Product Details

BearingNO.

Main Dimension

(mm)

      Load Rating (KN)

Max Runout Speed


  Weight  (kg)
  Bore Bore Width Radius Dynamic Static Grease Oil
  d D B r
              r/min r/min
        min
62200 10 30 14 0.6 2.38 5.1 24000 30000 0.049
62201 12 32 14 0.6 3.05 6.82 22000 28000 0.053
62202 15 35 14 0.6 3.72 7.65 19000 24000 0.059
62203 17 40 16 1 4.78 9.58 17000 20000 0.091
62204 20 47 18 1 6.65 12.8 15000 18000 0.131
62205 25 52 18 1 7.88 14 12000 15000 0.148
62206 30 62 20 1.5 11.5 19.5 10000 13000 0.236
62207 35 72 23 1.5 15.2 25.5 9000 11000 0.375
62208 40 80 23 2 18.6 18.2 8000 10000 0.604
62301 12 37 17 1 5.08 9.72 20000 26000 0.095
62302 15 42 17 1 5.42 11.5 19000 24000 0.113
62303 17 47 19 1 6.58 13.5 17000 20000 0.141
62304 20 52 21 1.5 7.88 15.8 16000 18000 0.197
62305 25 62 24 1.5 11.5 22.2 13000 16000 0.317
62306 30 72 27 2 15.2 27 11000 14000 0.473
62307 35 80 31 2 19.2 33.2 9000 11000 0.658
16001 12 28 7 0.3 5.08 2.38 27000 32000 0.024
16002 15 32 8 0.3 5.6 2.55 23000 28000 0.025
16003 17 35 8 0.3 6.8 3.38 21000 25000 0.032
16004 20 42 8 0.3 7.9 4.5 17000 21000 0.052
16005 25 47 8 0.3 8.8 5.6 15000 18000 0.059
16006 30 55 9 0.3 11.2 7.4 13000 15000 0.084
16007 35 62 9 0.3 12.2 8.8 11000 13000 0.107
16008 40 68 9 0.3 12.6 9.6 9800 12000 0.125
16009 45 75 10 0.6 15.6 12.2 8900 10000 0.155
16010 50 80 10 0.6 16.1 13.1 8200 9700 0.166
16011 55 90 11 0.6 19.4 16.2 7400 8800 0.207
16012 60 95 11 0.6 19.9 17.5 6900 8100 0.224
