Ball bearings Suppliers

Ball bearings

Ball bearings

DZ industrial.


Location:China
Business Type:Manufacturer, Exporter
Brands:
Certificate:ISO and TS
Model:
Terms of payment and delivery:Lc / TT 45days
Minimum order quantity:1000pcs
Price:contact
Packing details:industrial packing or box

Product Details

Bearing NO. Main Dimension(mm)       Load Rating (KN)   Max Runout Speed   Weight  (kg)
  Bore Bore Width Radius Dynamic Static Grease Oil
  d D B r
              r/min r/min
        min
685 5 11 3 0.15 0.6 0.28 36000 45000 0.001
686 6 13 3.5 0.15 0.83 0.39 34000 43000 0.002
687 7 14 3.5 0.15 0.901 0.441 32000 40000 0.002
688 8 16 4 0.2 1.029 0.539 30000 38000 0.003
689 9 17 4 0.2 1.078 0.588 28000 36000 0.003
6800 10 19 5 0.3 1.319 0.694 26000 34000 0.005
6801 12 21 5 0.3 1.473 0.833 22000 30000 0.006
6802 15 24 5 0.3 1.549 0.922 20000 28000 0.007
6803 17 26 5 0.3 1.639 1.041 19000 26000 0.008
6804 20 32 7 0.3 2.646 1.715 17000 22000 0.018
6805 25 37 7 0.3 2.84 1.96 15000 19000 0.022
6806 30 42 7 0.3 3.087 2.352 12000 16000 0.026
6807 35 47 7 0.3 4.9 4 11000 15000 0.03
6808 40 52 7 0.3 5.1 4.4 10000 13000 0.033
6809 45 58 7 0.3 6.2 5.4 8000 11000 0.04
6810 50 65 7 0.3 6.6 6.1 6000 9000 0.052
695 5 13 4 0.2 0.72 0.39 34000 43000 0.002
696 6 15 5 0.2 1.12 0.59 32000 40000 0.004
697 7 17 5 0.3 1.568 0.784 30000 38000 0.005
698 8 19 6 0.3 1.72 0.864 28000 36000 0.007
699 9 20 6 0.3 1.325 0.694 27000 34000 0.008
6900 10 22 6 0.3 2.54 1.37 25000 32000 0.009
6901 12 24 6 0.3 2.221 1.235 22000 28000 0.011
6902 15 28 7 0.3 2.639 1.501 20000 26000 0.016
6903 17 30 7 0.3 2.79 1.65 18000 24000 0.018
6904 20 37 9 0.3 5.03 3.063 17000 22000 0.036
6905 25 42 9 0.3 5.63 3.68 14000 18000 0.042
6906 30 47 9 0.3 5.82 3.97 13000 16000 0.048
6907 35 55 10 0.6 9.5 6.8 12000 15000 0.074
6908 40 62 12 0.6 13.7 9.9 11000 13000 0.11
6909 45 68 12 0.6 14.1 10.9 9000 11000 0.132
6910 50 72 12 0.6 14.5 11.7 5000 9000 0.133
